Trommel Screen

Trommel screens is a kind of precise classification equipment, it have a wide application, especially are ideal for the screening of compost, organics,glass, stone,wood waste,etc. EXCT can offer a wide range of model for different capacity, custom design also can be done according to customer’s needs. Trommel screens are designed to provide years of trouble-free classification, they can solve your separation question well.
Products
Application
Contact Us
Middle of Xinchang North Line, Xinxiang City, Henan Province, China
trommel screen STRUCTURE
The trommel screen is mounted obliquely on the frame. The motor is coupled to the drum unit via coupling and reducer to drive the drum unit to rotate about its axis. After the material enters the trommel screen, due to the tilting and rotation of the roller device, the material on the sieve surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the discharge port at the bottom of the rear end of the drum, and the unqualified material (upper screen product) is discharged through the discharge port at the end of the drum.
The trommel screen mainly consists of motor,reducer,roller device, frame, sealing cover and inlet & outlet. Due to the turning and rolling of the material in the drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being cloggedtrommel screen structure
OUTSTANDING ADVANTAGES

1.Barrel of trommel screen includes infeed diverter rings for minimizing the material loss.
2.Modular replaceable screen segments according to customer requirements. Customer choose woven wire and plate per their demands.
3.Trommel screens allow access to screens for maintenance and inspection.
4.Alternative discharge belt conveyor, EXCT can supply diverse belt conveyor for discharging material of after screened.
5.The main frame of heavy steel structure is designed with components for minimizing material accumulation.
6.Heavy duty structure includes integrated leveling system, it is easy to install.
7.Nylon bristle, cleaning device can be changeable quickly and individually for minimizing downtime of equipment, and that improving efficiency.
8.Trunnion components mounted to heavy duty roller bearings to prolong service life.
9.low stress welded, structural tubing lifter assemblies
10.Alternative feed and discharge chutes.

why choose EXCT trommel screen
driver device for trommel screen Driving device
Brand of driving device can choose on your request.
International brands like SEW, ABB, SUMITOMO, SIEMENS.
China brand like Yutong,Tailong,Guomao,Taixing,Nangaochi.
Powerful enclosed and compact efficient motor drive
Shaft mounted and underslung gearbox reducer.
Optimization YOX & YOT constant filling hydrodynamic coupling.
Good balance and strong braking force Brake.



Screen mesh
The mesh hole is not easy to block.
Screen mesh with special material wire mesh
High screening efficiency,
Bold material, heavy bearing, long use time
It is easy to replace the screen with a bead
According to the characteristics of the screening material, a fully enclosed structure or an open structure can be selected.



screen for trommel screen
trommel screen for frame Frame
The frame is integrally welded and formed with compact structure and high reliability.



TROMMEL SCREEN for MATERIAL
trommel screen material


SPECIFICATIONS

Model Length Range Segment No. Aperture Size Power
(Kw)
Inclined Angle Max. Material Size Rotating Speedrpm
GTSφ600 2-4m 1-2 30mm 2.2-3 0-7° 60mm 12-18
GTSφ800 2-5m 1-3 50mm 3-5.5 0-7° 100mm 12-18
GTSφ1000 2-6m 1-4 100mm 4-11 0-7° 150mm 10-18
GTSφ1200 3-8m 1-4 150mm 5.5-18.5 0-7° 200mm 9-15
GTSφ1500 3-10m 1-5 200mm 7.5-22 0-7° 250mm 9-15
GTSφ1800 4-12m 1-5 220mm 7.5-22 0-7° 270mm 8-15
GTSφ2000 5-15m 1-5 250mm 11-30 0-7° 300mm 8-12
GTSφ2500 5-18m 1-6 300mm 11-30 0-7° 350mm 8-12
customized according to your requirements

TROMMEL SCREEN CASE
trommel screen for construction waste

trommel screen for scraw leavel

Project: Trommel Screen for Municipal solid waste sorting system in Malaysia
Equipment Model: GTS2075         Material: Construction waste
Customer: Sunway Construction Group

Project: Trommel Screener for Compost production line in South Africa
Equipment Model: GTS1230          Material: Scraw/leaves
Customer: Green Building and Dominant Company
Selection instructions

1.Material to be screened: ______(We will appreciate if you can provide us the on-site photo for the material)
2.Handling capacity:______t/h
3.Bulk Density: ______t/m3
4.Material is corrosive or not: ______ (Yes or No)
5.Max. granule size of the feeding material: ______mm
6.Segment number: ______
7.Mesh size of each segment : ______mm
8.Particle distribution percentage:______
The following example will help you :
If the segment number is two, the mesh size of each segment is 50 mm and 25 mm, then you will get 3 kinds of products: X,Y, Z.Therefore, X ≥ 50 mm; 25 mm ≤ Y < 50mm; Z < 25 mm. And then the following information also need to be confirmed :
a.The X percentage in whole material:______%;
b.The Y percentage in whole material:______%;
c.The Z percentage in whole material:______%;
9.What equipment is used to feed the material into the trommel screen:______
10.Do the material after screened need to be transported by belt conveyor?______ (Yes or No)
11.Electric power supply:______V______HZ
12.Does the trommel screen work alone or with other equipment to form a system? If forming a system, do you have reliminary design or hand-drawn sketch? If have,Please send it to our engineer for reference.
13.Quantity required :______
